GRAND G340N
Small and mighty. Our tiny 3.3m/11ft inflatable tender boat with motor up to 40HP. Opening our elite yacht tender line, G340N is the little sister remastered to reestablish our classic 340 model with modern and functional upgrades. Kept super lightweight, this small RIB boat now provides an up to 7” screen dashboard, boosted power, comfort and more options, delivering a first class ride and transfer experience.
Technical Data
| Length overall | 3.25 m |
| Length internal | 2.60 m |
| Width overall | 1.75 m |
| Width internal | 0.80 m |
| Tube diameter | 0.32 - 0.45 m |
| № of chambers | 3 |
| Tube material | PVC or Hypalon |
| Board height | н/д |
| Draft maximum (when fully loaded) | н/д |
| Dry boat weight | 132.0 kg |
| Loading capacity | 540.0 kg |
| Passenger capacity | 4 persons |
| Fuel tank capacity | 40.0 l |
| № of motors | One |
| Engine recommended | 25 - 40 HP |
| Engine weight max | 105.05 kg |
| Engine shaft length | S: 20 inch / 508 mm |
| Midsection / aft deadrise (degrees) | 18° / 17° |
| Hull type | RIB |
| Boat design category | C |
| Package dimensions №1 | 3040×1290×820 (h) mm |
| Package dimensions №2 | 830×810×510 (h) mm |
| Boat weight in package | 204.0 kg |
1 – Bow anchor storage compartment
2 – Bow locker
3 – Storage compartment in steering console
4 – In-built fuel tank compartment (40 l)
5 – Rear locker / dry storage compartment
1 – Fiberglass «Medium-V» hull «High-Step-Hull» (HSH) with enlarged cockpit «DART Hull» and transom extension «Swallow tail»
2 – 3-chamber variable cross-section inflatable tube «DART»
3 – Rubbing strake with spash gurad
4 – Steering console CL-31 with small storage compartment, with windscreen; Dashboard (can accommodate MFD up to 7′)
5 – Steering wheel, mechanical steering system (T71), steering cable (M66)
6 – Bow locker
7 – Steering console with side seat (optional)
8 – Integrated aft locker/sofa
9 – Bow step plate with retract push-up cleat
10 – SeaDek soft anti-skid flooring
11 – Bow handle
12 – Safety handles
13 – Two safety handrails on the side of the aft settee on the inflatable tube
14 – Two stern retractable cleats in polished stainless steel
15 – D-shaped towing eyelets
16 – Inflation/deflation valves / Overpressure valve
17 – Waterski towing mast
18 – Corrugated hose exit from the interdeck space for concealed installation of utilities
19 – Reinforced transom
20 – GRP stepends of the inflatable tube
Gallery
Equipment
Standard equipment
-
3-chamber variable cross-section inflatable tube «DART» with GRP stepends, handles, rubbing strake, towing units
-
Bow step plate with retract push-up cleat
-
Fiberglass «Medium-V» stepped hull and transom extension «Swallow tail»
-
Bow and aft storage compartment
-
Steering console CL-31 with small storage compartment, with windscreen; Dashboard (can accommodate MFD up to 7′)
-
Mechanical steering system (T71), steering cable (M66)
-
Steering wheel
-
Integrated aft settee
-
Set of seating cushions and backrests, Silvertex upholstery
-
Two safety handrails on the side of the aft settee on the inflatable tube
-
Stainless steel cupholder on the steering console
-
Hull ventilation system
-
Anti-skid deck surface
-
Self-draining cockpit with drainage system
-
Inspection hatch
-
Corrugated hose in the interdeck space for concealed installation of communications
-
Two stern retractable cleats in polished stainless steel
-
Integrated towing & lifting eyes
-
Two collapsible oars
-
Foot pump, repair kit and owner’s manual
Optional equipment
-
Overpressure valves
-
Removable side seat kit
-
Upgrade CL-31 to a double steering console with side seat, locker and cupholder
-
SeaDek soft anti-skid flooring
-
Electric package
-
Inbuilt fuel system with 40lit / 10gal tank
-
Waterski towing mast
-
Black powder coated stainless steel upgrade
-
Canvas bimini-top, collapsible
-
Overall, console & rear seat covers
-
Keel & tube protector package
Outboard motors
YAMAHA F25GETL
|
YAMAHA F30BETL
|
YAMAHA F40FETL
|
|
|---|---|---|---|
| Engine type | 4-Stroke, SOHC, In-Line 2 | 4-Stroke, SOHC, In-Line 3 | 4-Stroke, SOHC, In-Line 3 |
| Displacement | 432 cm³ | 747 cm³ | 747 cm³ |
| Bore × Stroke | 65.0 × 65.1 mm | 65.0 × 75.0 mm | 65.0 × 75.0 mm |
| Max. prop shaft output | 18.4 kW / 25 hp | 22.1 kW / 30 hp | 29.4 kW / 40 hp |
| Fuel induction system | Electronic Fuel Injection (EFI) | Electronic fuel injection | Electronic Fuel Injection (EFI) |
| Lubrication system | Wet sump | Wet sump | Wet sump |
| Engine transom height (Shaft length) | L: 553 mm (21.8 inch) | L: 536 mm (21.1 inch) | L: 536 mm (21.1 inch) |
| Weight | 64,0 kg | 98,0 kg | 98,0 kg |
| Engine Start | Electronic Starter | Electronic Starter | Electronic Starter |
| Steering | Remote Control | Remote | Remote |
| Trim Control System | Power trim and tilt | Power trim and tilt | Power trim and tilt |
| more | more | more |
Fiberglass hull colors
Tube colors
Upholstery colors (UPholstery colors)
SeaDeck colors
Steering wheel
Standard equipment
-
5-chamber inflatable tube with GRP stepends and handles (6+1 pcs), PVC 1100 g/sq.m. (color to choose), two D-shaped towing ringsBow step plate with retract push-up cleatFiberglass «Medium-V» stepped hull and transom extension (white color)Bow and aft storage compartmentSteering console CL-31 with small storage compartment, with windscreen; Dashboard (can accommodate MFD up to 7')Mechanical steering system (T71), steering cable (M66)Steering wheelIntegrated aft setteeSet of seating cushions and backrests, Silvertex upholsteryTwo stainless steel safety handrails on the side of the aft settee on the inflatable tubeStainless steel cupholder on the steering consoleHull ventilation systemAnti-skid deck surfaceSelf-draining cockpit with drainage systemInspection hatchCorrugated hose in the interdeck space for concealed installation of communicationsTwo stern retractable cleats in polished stainless steelOne bow and two rear stainless steel D-bolts for securing/transporting the boat on a trailerPad eyes stainless steel for lifting the boat with a crane beamTwo collapsible paddlesHi volume foot pumpRepair kit and owner's manual
Factory equipment
Optional equipment
Mechanical Remote Controli
Installation kit (6X3+6Y8 Tacho) for outboard motors 20-70HP:
• 6X3 Remote Control Flush Mount (left side)
• 6Y8 Round Tachometer Kit
• 6R5 Panel switch assy Single
• Main harness 10P
• Premium remote control cable (YPM) – 2 pcs.
• Water/Fuel Separator Filteri
Y-COP Attachment Kit
i
Propeller Aluminum, White, F
i
Installation kit (6X3+6Y8 Tacho) for outboard motors 20-70HP:
• 6X3 Remote Control Flush Mount (left side)
• 6Y8 Round Tachometer Kit
• 6R5 Panel switch assy Single
• Main harness 10P
• Premium remote control cable (YPM) – 2 pcs.
• Water/Fuel Separator Filteri
Installation kit (6X3+6Y8 Tacho+Speedo/FMM) for outboard motors 30-70HP:
• 6X3 Remote Control Flush Mount (left side)
• 6Y8 Round Tacho + Speedo/FMM Kit (+ Electronic speed sensor kit)
• 6R5 Panel switch assy Single
• Main harness 10P
• Premium remote control cable (YPM) – 2 pcs.
• Water/Fuel Separator Filteri
Y-COP Attachment Kit
i
Propeller Aluminum, White, G
i
Propeller Black Stainless Steel, G
i
Installation kit (6X3+6Y8 Tacho) for outboard motors 20-70HP:
• 6X3 Remote Control Flush Mount (left side)
• 6Y8 Round Tachometer Kit
• 6R5 Panel switch assy Single
• Main harness 10P
• Premium remote control cable (YPM) – 2 pcs.
• Water/Fuel Separator Filteri
Installation kit (6X3+6Y8 Tacho+Speedo/FMM) for outboard motors 30-70HP:
• 6X3 Remote Control Flush Mount (left side)
• 6Y8 Round Tacho + Speedo/FMM Kit (+ Electronic speed sensor kit)
• 6R5 Panel switch assy Single
• Main harness 10P
• Premium remote control cable (YPM) – 2 pcs.
• Water/Fuel Separator Filteri
Y-COP Attachment Kit
i
Propeller Aluminum, White, G
i
Propeller Black Stainless Steel, G
